Product Introduction

The ABB PP836 3BDE042237R1 is a 6.5-inch physical function key HMI panel of ABB Panel800 series, compatible with System 800xA and AC800M controllers. It features 640×480 TFT color display, 16 physical function keys and 16 bi-color LED indicators, powered by 24VDC with front IP65 protection rating. Equipped with Ethernet, RS232, RS485 and USB ports, it supports real-time process monitoring, manual operation, alarm display and event logging, configured via Panel Builder 800 software. Widely used in power, chemical, pulp & paper and water treatment industries.

Content Details

ABB PP836 acts as human machine interface for ABB 800xA automation platform. It communicates with AC800M controller over Ethernet to collect field process data, display process graphics and receive operator commands via physical keys. It supports alarm event recording and trend storage for on-site fault analysis. Front IP65 rating delivers dust and splash resistance for cabinet cutout mounting. Multiple communication ports connect to controllers, and USB interface supports project backup and restore. Built-in hardware diagnostics monitor display, keys, communication links and internal circuit. With die-cast aluminum front housing and wide operating temperature range, this key panel runs stably under industrial vibration and electromagnetic interference. PP836 is used for engineering commissioning and spare replacement of ABB 800xA DCS. Before shipment, each unit undergoes full functional test and thermal aging inspection to eliminate hidden defects and guarantee reliable long-term continuous operation.
