Product Introduction

The ABB CI810V1, part number 3BSE008584R1, is an AF100 fieldbus communication interface module for ABB AC800M, Advant OCS and 800xA distributed control systems. It serves as the communication bridge between the main controller and S800 remote I/O stations over AF100 twisted-pair fieldbus. It transmits real-time analog/digital process signals, control commands and diagnostic information between the control rack and distributed field I/O units. Adopting industrial-grade circuit design and excellent EMC anti-interference performance, the module delivers stable fieldbus communication under tough industrial conditions including temperature fluctuation, dust, vibration and strong electromagnetic noise. Widely used in power, petrochemical, pulp & paper, metallurgy and water treatment industries. It is a critical spare part for DCS cabinet maintenance, AF100 communication module replacement and legacy automation system renovation.

Content Details

Brand: ABB Model: CI810V1 Part No: 3BSE008584R1 Product Type: AF100 Fieldbus Communication Interface Module Applicable System: ABB AC800M, Advant OCS, 800xA DCS, S800 I/O System Bus Protocol: AF100 (Advant Fieldbus 100) The ABB CI810V1 3BSE008584R1 is a plug-in rack module installed inside the DCS control cabinet. It connects the controller internal bus and AF100 fieldbus network. It collects measuring signals and digital status feedback from S800 remote I/O stations, and sends controller output commands to field actuators. It handles cyclic real-time data exchange for continuous process control and acyclic communication for parameter configuration and fault diagnosis. This module supports hot-swap function. Maintenance technicians can replace the module without shutting down the whole control rack to reduce plant downtime during overhaul. It supports dual media redundancy for AF100 bus to improve communication reliability for high-availability process sites. Every unit undergoes full functional testing and aging screening before shipment to guarantee stable 24/7 continuous operation. Built-in signal isolation and surge protection suppress voltage spikes and ground loop interference, protecting the main controller from electrical faults originating on the fieldbus side. It can be configured and diagnosed via ABB Control Builder and Advant engineering software. LED indicators on the front panel show power status, AF100 bus activity and fault alarms, helping maintenance staff quickly locate fieldbus failures and shorten equipment outage time. Multiple S800 I/O units can be linked on the AF100 bus to expand DCS input and output capacity. Typical application scenarios include thermal and hydro power plant DCS control, chemical continuous process monitoring, paper mill automation, metallurgical production line and municipal sewage treatment automation. When the original AF100 communication interface fails, CI810V1 3BSE008584R1 can be directly replaced to restore AF100 fieldbus communication between DCS controller and S800 remote I/O stations. This module complies with CE, UL and IEC industrial safety and EMC standards with IP20 protection rating. Compact modular rack layout and durable electronic components support long-term stable operation. Whether you prepare spare inventory for equipment overhaul or purchase components for DCS retrofit projects, the ABB CI810V1 AF100 communication module provides reliable fieldbus connectivity for your ABB automation system.
